Cargo E-Tricycle
800W–1200W motor · 60V/72V · 150–500L cargo box · 300 kg payload
Standard Configuration
| Motor | 800W / 1000W / 1200W brushless hub motor with differential, 60V/72V |
|---|---|
| Battery | 60V 32Ah / 72V 40Ah lithium (LFP available), heavy-duty BMS |
| Range | 50–80 km (loaded 200 kg, flat terrain) |
| Top Speed | 25–35 km/h |
| Charging Time | 6–10 hours (5A charger) |
| Brakes | Hydraulic disc front + dual drum rear, parking brake |
| Weight | 150–220 kg (without cargo box) |
| Load Capacity | 300 kg (EU) / 500 kg (non-EU), box volume 150–500L |
| Tires | 3.00-12 front / 3.75-12 rear (dual), reinforced load-rated |
| Frame | Steel tube chassis, heavy-duty e-coat + powder coat, rust-resistant |
| Cargo Box | Aluminum sheet / steel with drop-sides, optional insulated lining |
| Display | LCD with speed, battery %, load indicator, reverse gear |
| Transmission | Forward / Neutral / Reverse gear selector, 3-speed |
| Lights | Full LED system, beacon light optional, reflectors |
OEM Options
The cargo box is the defining component of this vehicle and our OEM program treats it as a blank-slate engineering project for every order. We fabricate boxes in welded aluminum sheet for corrosion resistance and weight savings, galvanized steel for impact-heavy duty cycles, or insulated sandwich panel construction for cold-chain food and pharmaceutical delivery. Box configurations range from a simple fixed flatbed with stake sides to a three-way drop-side body that converts to a flatbed in seconds, and a hydraulic tipper mechanism for construction material, agricultural produce, or waste collection applications. Refrigeration units from 12V DC compressor systems maintain a 2–8 degrees Celsius cold chain for last-mile grocery and medical deliveries. On the drivetrain, motor power scales from 800W for flat urban routes to 1200W with hill-climb gearing for cities built on steep terrain. Battery chemistry defaults to NMC but we strongly recommend LFP for operators in tropical or desert markets where pack longevity under thermal stress matters more than energy density. Fleet-focused options include GPS tracker integration with geofencing, a reverse alarm for warehouse safety compliance, and a solar panel roof that trickle-charges the auxiliary battery to extend daily range by 8–12 km.
- Cargo box dimensions & material (aluminum/steel/insulated sandwich panel)
- Box configuration (fixed/drop-side/tipper)
- Refrigeration unit for cold chain
- Box branding (vinyl wrap/paint/silkscreen)
- Motor power (800W–1200W with hill-climb gearing)
- Battery chemistry (LFP for tropical/desert markets)
- Canopy/rain cover
- Shelving & partition interior
- Solar panel roof for extended range
- GPS tracker integration
- Reverse alarm
Certifications
Cargo tricycles straddle commercial vehicle regulations in many jurisdictions, so we provide the ECE R10 electromagnetic compatibility certification as standard on every unit — this is the same EMC standard applied to four-wheeled commercial vehicles and it satisfies the radiated and conducted emissions requirements that customs authorities in the EU, GCC, and ASEAN regions increasingly enforce on electric cargo carriers. CE marking covers the full electrical system including the motor controller's surge protection and the BMS cell-balancing logic. RoHS documentation traces every solder joint, connector pin, and PCB substrate in the vehicle's electronics to compliant material declarations. The larger battery packs used in cargo configurations (72V 40Ah) undergo UN 38.3 testing with specific attention to the crush and impact tests, given the higher stored energy compared to passenger variants. Our ISO 9001:2015 certified assembly line maintains a per-vehicle inspection checklist that covers weld integrity on the cargo subframe, torque verification on all chassis fasteners, and a loaded road test with 300 kg of ballast to confirm brake balance and motor thermal behavior under real-world duty cycles.
MOQ: 50 units · Lead time: 25–35 days (box customization +10 days) FOB Shenzhen
Related Industries
Cargo & Logistics
The 300–500 kg payload capacity and configurable box volume from 150 to 500 liters make this platform a direct replacement for a light commercial van on intra-urban distribution routes under 15 km. Consolidation centers can operate a fleet of twenty cargo e-trikes for the cost of three diesel vans, with zero tailpipe emissions inside low-emission zones and pedestrianized city centers.
Delivery & Last-Mile
E-commerce fulfillment centers and postal operators use customizable shelving interiors to organize parcels by delivery sequence, cutting curb-side sorting time by 40% compared to a panel van where packages stack in a single volume. The Forward/Neutral/Reverse gear selector lets drivers execute tight three-point turns in alleyways without three-point shuffling.
Government & Municipal Fleet
Waste management departments, park services, and public works agencies deploy cargo e-trikes for applications where a full-size truck is overkill: street-sweeping support, park bench maintenance runs, public event logistics, and segregated waste collection in pedestrian zones. The optional tipper box with hydraulic lift handles loose material like green waste or sand with a single-operator workflow.
Cargo E-Tricycle in Detail
Cargo E-Tricycle FAQ
Choose Your Cargo Tricycle Configuration
| Specification | Light 800W | Standard 1000W | Heavy-Duty 1200W LFP |
|---|---|---|---|
| Motor | 800W hub, 60V | 1000W hub, 60V | 1200W hub, 72V |
| Battery | 60V 32Ah NMC | 60V 32Ah NMC | 72V 40Ah LFP |
| Range (loaded) | 50–60 km | 60–70 km | 70–80 km |
| Payload (EU/non-EU) | 300 / 500 kg | 300 / 500 kg | 300 / 500 kg |
| Box Volume | 150–300L | 200–400L | 300–500L |
| Weight | 150–180 kg | 170–200 kg | 190–220 kg |
| Price (FOB) | $1,250–1,550 | $1,580–1,880 | $1,880–2,250 |
| MOQ | 50 units | 50 units | 50 units |
All prices FOB Shenzhen. Range estimates based on 200 kg load, flat terrain, 25 km/h average speed. Quantity discounts at 100, 200, and 500 units.
Cargo E-Tricycle Ordering Guide
Cargo tricycles ship with the cargo box removed and flat-packed separately for space efficiency. The chassis ships in a welded steel crate measuring approximately 260 x 120 x 145 cm.
- 20GP container: 8–10 units (chassis only, boxes flat-packed separately)
- 40HQ container: 20–24 units standard; up to ~30 complete units with boxes nested for maximum density
- Box packing: Cargo boxes flat-packed on pallets, nested to reduce volume. Reassembly at destination takes approximately 45 minutes per unit with basic hand tools
- Sea freight: 30–40 days to major ports (Rotterdam, Los Angeles, Dubai, Mombasa, Santos)
Configure Your Cargo E-Tricycle Fleet
Tell us your cargo dimensions, payload requirement, box material preference, and whether you need cold chain capability. Our engineering team delivers a dimensional drawing, BOM, and FOB quotation within one business day.
